Features;
The FC5000 and T100 Series Desktop Centrifuges provide a reliable and fast operation thanks to the Brushless DC Motor and Micro Processor controlled system.
The front panel's Soft-Touch keys and LCD display make it easy to control and monitor parameters such as RPM, RCF, Time and Cover status.
The devices provide high quality service to the user by preventing the heating of samples due to the necessary heating balance protection equipments or air exchange channels, preventing contamination and similar distortions.
External design made of very robust hair and stainless steel materials provides reliable and comfortable operation with balance control and cover security systems.
Each of the models offers a wide range of rotor capacities.
The FC5000 Series is a series produced for a wide range of applications from Biochemistry to Microbiology. It is one of our ideal solutions for blood tube centrifugation especially in health centers and hospitals.
The centrifuge device has 10 steps of acceleration and deceleration.
The Normal Operating Condition;
- Ambient Temperature: 5°C – 40°C
- The Relative Humidity: ≤80% (RT 25°C)
Technical Specifications;
| MODEL | FC5000-1B | FC5000-4 | T100-A/1 | T100-A/2 | T100-C |
| Max. Speed (RPM) | 5000 | 5000 | 10000 | 16000 | 16000 |
| Max. RCF (xg) | 4360 | 5180 | 11000 | 18320 | 18320 |
| Timer Range | 1-999min | ||||
| Control | Microprocessor Control | ||||
| Motor | Brushless Motor | ||||
| Noise | ≤60dB | N/A | N/A | N/A | N/A |
| Power Supply | AC220V 50Hz 5A | AC220V 50Hz 8A | |||
| Dimension (LxWxH)(mm) | 510x410x310 | 670x560x450 | 510x410x310 | 310x240x200 | 370x290x260 |
| Package Dimension (LxWxH)(mm) | 515x590x410 | N/A | N/A | N/A | N/A |
| Net Weight (kg) (Without Rotor) | 25,5 | 62 | 36 | 18 | 24 |
| Gross Weigh (kg) (With Rotor) | 28,5 | 65 | 39 | 21 | 27 |
Block Types;
| MODEL ROTOR TYPE |
MODEL | FC5000-1B | FC5000-4 | T100-A/1 | T100-A/2 | T100-C |
|
CAPACITY |
RPM RCF(xg) | RPM RCF(xg) | RPM RCF(xg) | RPM RCF(xg) | RPM RCF(xg) | |
| ANGLE ROTOR | 12 x 0.5ml | 16000 18320 | 16000 18320 | |||
| 48 x 0.5ml | 13500 18320 | |||||
| 12 x 1.5ml | 16000 18320 | 16000 18320 | ||||
| 24 x 1.5ml | 13500 18320 | |||||
| 4 x 5ml | 10000 11000 | |||||
| 12 x 5ml | 15000 18320 | |||||
| 10 x 7ml | 13500 18320 | |||||
| 4 x 10/15ml | 10000 11000 | |||||
| 12 x 10/15ml | ||||||
| 24 x 10/15ml | 10000 11000 | |||||
| 10 x 20ml | ||||||
| 6 x 50ml | 10000 11000 | |||||
| 4 x 100ml | 10000 11000 | |||||
| SWING ROTOR | 24 x 5ml | 4500 4360 | ||||
| 40 x 5ml | 4500 4360 | |||||
| 24 x 7ml | 4500 4360 | |||||
| 60 x 7ml | 4500 4360 | |||||
| 120 x 7ml | 3500 4850 | |||||
| 88 x 5/7ml | 3500 4850 | |||||
| 8 x 10/15ml | 5000 4360 | |||||
| 12 x 10/15ml | 5000 4360 | |||||
| 16 x 10/15ml | 5000 4360 | |||||
| 24 x 10/15ml | 5000 4360 | |||||
| 28 x 10/15ml | 5000 5180 | |||||
| 32 x 10/15ml | 5000 4360 | |||||
| 64 x 10/15ml | 4000 3400 | |||||
| 72 x 10/15ml | 3500 4850 | |||||
| 32 x 15ml | 3500 3400 | |||||
| 36 x 20ml | 3500 4850 | |||||
| 8 x 50ml | 5000 4360 | |||||
| 16 x 50ml | 3500 3400 | |||||
| 4 x 100ml | 5000 4360 | |||||
| 8 x 100ml | 4000 3400 | |||||
| 4 x 500ml | 3500 4850 |
