INOS-ROP Series High Quality Pure Water System

Features:



INOS-ROP series produce high quality pure water with superior resistivity and low TOC (<30ppb).





Microprocessor Control

  • Fully automatic and self-diagnostic system monitors and controls working condition.
  • PIN-coded access to software set points prevents unauthorized changes to operation or system settings.





Comprehensive Sanitization

  • Unlike many other systems, Heal Force entire fluid pathway is included in the automated disinfection process ensuring complete sanitization.



Module-designed Cartridges

  • High quality and economical due to disposable integrated purification column design.
  • Easy replacement and quick connection.





High precision resistivity meter

  • Flow-through structure make sure the real-time measurement of the actual ionic concentration in water
  • Low cell constant (0.01cm-1) to ensure optimum measurement accuracy of low ionic contamination
  • Automatic temperature compensation (0.1℃ resolution) makes the value displayed on the screen meaningful





Easy-to-read LCD display

  • User-friendly LCD provides optimal convenience, with indication on resistivity, resistivity, reservoirs water consumable changing reminder water quality.





Optional strengthened pre-treatment module

  • 20' size long cartridge contrains detergent. Therefore, besides the feature of higher water throughput, feed water with extremely low quality can be properly dealt with





Contamination-Free Water Tank

  • Water level sensor combined with bottom pump enables 5-level automatic water production controls
  • Capacity of water reservoir includes 30L and 60L. Moreover, ultra big 350L water reservoir is available for special needs
  • The water reservoir is made through cylindrical mold and blow molding process to avoid the generation of velum
  • PE material ensure low extractives
  • Overflow protection tube eliminates the risk of flooding
  • Cone shape bottom guarantees no stagnant water and facilitates easy clean
  • Optional UV lamp and vented filter maintain consistent purity of stored water and provide effective protection against airborne contaminants





Network Compatible

  • RS232 port allows for data collection and permanent record of water quality and system parameters, with date and time, to a PC or printer - essential for compliance with good laboratory practice guidelines


Technical Specifications:



Type INOS-ROP (Bench Top) INOS-ROP (Floor Type)
Model ROP-15 / ROP-30 ROP-50 / ROP-100 / ROP-150
Feed Water Requirement
Source Tap water
Conductivity <2000us/cm
Hardness <450ppm as CaCO3
Pressure 0.05~0.5MPa(7-72psi)
Temperature 5~40˚C
Purification Water(Class III)
Ionic Rejection >95%
Bacteria Rejection >99%
Conductivity 1~20us/cm(RO-2 5us/cm)
Productivity Rate 15L/h,30L/h 50L/h,100L/h,150L/h
High Quality Purification Water(Class II)
Resistivity At 25˚C 10MΩ.cm
TOC <30ppb
Dissolved Organic <0.1ppm
Particulate(≥0.02um) <1pc/ml
Bacteria <1cfu/ml
Flow Rate 1.5~2.0L/min 2~2.5L/min
Electrical Requirements
Electrical Voltage 110V/220V±10%
Electrical Frequency 50Hz/60Hz
Packing Information(Net Weight)
Main Units 25kg 90kg
Water Tank(30L/60L) 7kg 10kg
External Dimensions(WxDxH)
Main Units 315x525x570mm 660x570x1160mm
Water Tank(30L/60L) 380x380x595mm 380x380x885mm
Shipping Weight
Main Units 37kg 112kg
Water Tank(30L/60L) 13kg 13kg
Shipping Dimensions(WxDxH)
Main Units 525x610x770mm 640x680x1165mm
Water Tank(30L/60L) 520x440x615mm 510x430x895mm
