Features:
-Ultra-pure water from purified water.
-The purified water quality required as feed water.
-Tap water subjected to ion exchange, reverse osmosis or distillation.
-Optimally, the purified water supplied by a INOVIA Smart E/ Smart RO system.
-The content of organic and inorganic substances in the feedwater are reduced to values approaching their limites by the serial combination of high-efficiency of INOVIA purification technologies.
Configurations:
| INOS-P System | INOS-PUV | INOS-PVF |
| Storage Tank 30L | ✓ | ✓ |
| Dual Wavelength UV-lamp | ✓ | ✓ |
| Ultra-Purification Cartridge | ✓ | ✓ |
| Micro-Filtration Cartridge | ✓ | x |
| Ultra-Filtration Cartrige | x | ✓ |
| Point-of-use Filter | ✓ | ✓ |
| Air Filter Net For Tank | ✓ | ✓ |
| Remote Water Dispenser | ✓ | ✓ |
Technical Specifications:
| Model | INOS-PUV | INOS-PVF | ||
| Feed Water Requirement | ||||
| Source | RO, Distilled, DI water (Conductivity<20μs/cm) | |||
| Temperature | 5～40˚C | |||
| Ultrapurification Water(Class I) | ||||
| Resistivity At 25˚C | 18.2MΩ.cm | |||
| Conductivity At 25˚C | 0.055us/cm | |||
| Flow Rate | 1.5～2.0L/min | |||
| TOC Level | 1～5ppb | |||
| Endotoxin(Pyrogens) | N/A | <0.001EU/ml | ||
| Particulate(≥0.02um) | <1pc/ml | |||
| Bacteria | <0.1cfu/ml | |||
| Rnase/Dnase | N/A | Free | ||
| Electrical Requirements | ||||
| Electrical Voltage | 110V/220V±10% | |||
| Electrical Frequency | 50Hz/60Hz | |||
| Packing Information(Net Weight) | ||||
| Main Units | 18kg | |||
| Water Tank(30L) | 5kg | |||
| External Dimensions(WxDxH) | ||||
| Main Units | 315x525x570mm | |||
| Water Tank(30L) | 380x380x595mm | |||
| Shipping Weight | ||||
| Main Units | 31kg | |||
| Water Tank(30L) | 13kg | |||
| Shipping Dimensions(WxDxH) | ||||
| Main Units | 525x610x770mm | |||
| Water Tank(30L) | 520x440x615mm | |||
