InoElisaR-1 Series is a high-quality light absorption microplate (elisa) reader based on filter with a wavelength range of 340nm - 750nm.
It is suitable for scientific research and clinical applications. The 7-inch touch color LCD screen does not require a keyboard and is easy to use.
Data and programs can be saved to the device or exported via USB. With plate reading speed, it can quickly perform measurement and provide measurement results with high accuracy and good repeatability.
Some basic features;
> Absorbance Range: 0.0 - 4.000 Abs meet different measurement requirements.
> 8 Position filter wheel. It is supplied with 4 standard filters and can also be used with other optional filters.
> The detection speed is fast and the entire 96-well microplate detection can be completed within 6 seconds.
> Incubation temperature range is between RT+4°C and 50°C. (Only for ElisaR-1T)
> High-resolution 7-inch touch color LCD screen does not require a keyboard and is easy to use.
> Onboard software can provide device control and data analysis and connect directly to a USB.
> The Microplate (Elisa) reader is equipped with standard control and data analysis software, which is convenient and fast for data detection.
Technical Specifications
|
Model |
InoElisaR-1 |
InoElisaR-1T |
|
Display |
7" Touch Screen |
7" Touch Screen |
|
Light Source |
Quartz-Halogen Lamp 6V 10W |
Quartz-Halogen Lamp 6V 10W |
|
Wavelength Range |
340nm - 750nm |
340nm - 750nm |
|
Filter |
8-position filter wheel Standard 4 filters : 405, 450, 492, 630nm Other filters are optional |
8-position filter wheel Standard 4 filters : 405, 450, 492, 630nm Other filters are optional |
|
Read-out Range |
0 - 4000 Abs |
0 - 4000 Abs |
|
Linearity |
[0.000 - 3.000 Abs) R²≥0.995 |
[0.000 - 3.000 Abs) R²≥0.995 |
|
Resolution |
0.001 Abs |
0.001 Abs |
|
Wavelength Accuracy |
≤±2nm |
≤±2nm |
|
Absorbance Repeatability |
[0.3 Abs] CV ≤.0.3% [3.4 Abs] CV ≤1% |
[0.3 Abs) CV≤0.3% [3.4 Abs) CV≤1% |
|
Absorbance Stability |
≤0.005 Abs [0.3 Abs] ≤2.0% [3.4 Abs] |
≤±0.005 Abs [0.2 Abs] ≤0.3% [2.3 Abs] ≤2.0% [3.4 Abs] |
|
Absorbance Accuracy |
≤±0.005 Abs [0.2 Abs] ≤±0.01 Abs [2.3 Abs] ≤±1.5% [3.4 Abs] |
≤±0.005 Abs [0.2 Abs] ≤±1% [2,3 Abs ] ≤±1.5% [3.4 Abs] |
|
Sensitivity/Detector |
≥0.01 A/photodiode |
≥0.01 A/photodiode |
|
Test Speed |
6s/96-well, fast measurement mode; Single wavelength <15 s/96 well Dual wavelengths <28 s/96 well (normal mode) |
6s/96-well, fast measurement mode; Single wavelength <15 s/96 well Dual wavelengths <28 s/96 well (normal mode) |
|
Incubator |
RT+4°C - 50°C |
|
|
Temperature Stability & Uniformity |
±0.5°C (at 37°C) |
|
|
User Interface |
Built-in software, Touch screen input, External mouse |
Built-in software, Touch screen input, External mouse |
|
Storage |
1000 test records |
1000 test records |
|
Port |
3 USB Ports (For PC, Printer and USB) |
3 USB Ports (For PC, Printer and USB) |
|
Power Supply |
AC 100/240V, 50/60Hz, 2A |
AC 100/240V, 50/60Hz, 2A |
|
Dimension (WxDxH) |
295x440x225mm |
295x440x225mm |
|
Weight |
10 Kg |
11 Kg |
