1. High-definition LCD Touch Screen, simultaneously displaying operational parameters: speed, temperature, vacuum, and running time.
2. Delayed start: after reaching a fixed speed, Start the vacuum pump to effectively prevent sample mixing.
3. Fully automatic vacuum control system, vacuum setting range 0.1~1000 mbar, Control accuracy 0.1 mbar.
4. 1.5/2ml Rotor stacking for simultaneous use; rotor replacement without tools.
5. Programmable with temperature and pressure settings; capable of storing 36 programs
6. Compatible with various rotor heads; transparent glass window for easy observation.
7. Magnetic drive: maintenance-free, non-contact drive, fully sealed.
8. Safety in use: inductive electric self-suction door lock ensures the centrifugal concentrator can only start when the door cover is fully closed and locked.
9. Freeze Drying Function: Can be used in conjunction with freeze-drying systems
You can download PDF-Broshure in the Documents below !
| Parameter | CVC-200 | CVC-200R | CVC-400 | CVC-400R |
| Temp. Range | Room Temperature ~ +80°C | -10°C ~ +80°C | Room Temperature ~ +80°C | -10°C ~ +80°C |
| Temp. Accuracy | ±1°C | ±1°C | ±1°C | ±1°C |
| Max. Speed | 2500 rpm | 2500 rpm | 2500 rpm | 2500 rpm |
| Max. Capacity | 6 x 100 ml | 6 x 100 ml | 12 x 100 ml | 12 x 100 ml |
| Timer | 0 ~ 99h 59min | 0 ~ 99h 59min | 0 ~ 99h 59min | 0 ~ 99h 59min |
| Vacuum Control Range | 0.1 ~ 1000 mbar | 0.1 ~ 1000 mbar | 0.1 ~ 1000 mbar | 0.1 ~ 1000 mbar |
| Main unit withstands vacuum levels | 0.01 mbar | 0.01 mbar | 0.01 mbar | 0.01 mbar |
| Noise | ≤ 55 dBA | ≤ 65 dBA | ≤ 58 dBA | ≤ 68 dBA |
| Power | 0.7 kW | 0.9 kW | 0.7 kW | 0.9 kW |
| Power Supply | 220V, 50Hz | 220V, 50Hz | 220V, 50Hz | 220V, 50Hz |
| Dimension (L x W x H mm) | 360 * 448 * 304 | 440 * 653 * 420 | 440 * 536 * 304 | 540 * 653 * 420 |
| Rotor Type | Rotor Volume |
| Angle Rotor | 42 x 1.5/2 ml |
| Angle Rotor | 108 x 1.5/2 ml |
| Angle Rotor | 48 x 5 ml |
| Angle Rotor | 30 x 10 ml |
| Angle Rotor | 24 x 15 ml |
| Angle Rotor | 8 x 50 ml |
| Angle Rotor | 6 x 100 ml |
| Angle Rotor | 16 x 20 ml Sample vial |
| Angle Rotor | 16 x 5 ml + 8 x 4 ml + 8 x 3 ml |
| Microplate Rotor | 2 x 96 well |
